Example

Why this example

Hand-written code and LLM-written code both drift. A pagination parameter or an access check comes out slightly differently each time a person or a model writes it again. Shelf keeps clay/model.json as the gauge, and every generated file is checked against it. A master gauge did this job in 19th-century interchangeable-parts manufacturing: a part passed when it matched.

Shelf is a small app you can run and share. One entity, Note. The model is the source. Clay writes the types, the page, the forms, and the handlers. You write the business rule once, in a touch file, and a spec sits next to it. The repository is morkeleb/clay-example.

git clone https://github.com/morkeleb/clay-example.git
cd clay-example
npm install
npm run dev

Open http://127.0.0.1:4317. The header has a role control. It sends the x-role header. A reader can list notes. A reader who submits a form gets HTTP 403. An editor can create a note and rename a note. The store is in memory and starts with two notes. npm run dev works after install, because the generated files are already in the project.

How Clay is set up

clay/model.json owns the fields, the queries, and the mutations. Six generators sit under clay/generators/, one folder each, created with clay init generator. Clay overwrites src/generated/. It writes each file under src/logic/ once, then leaves it. src/runtime/ is the server, the store, and the page script, written by hand.

The index page shows the note list and the selected note.

1. The list calls the generated list query.
2. A click calls the generated get query and shows that note.
3. The note has one button for each mutation.
4. The button opens the form for that mutation.
5. The form sends JSON to the generated handler.
6. The handler checks the caller role against the mutation permission.
7. The handler calls the touch file in src/logic.
8. The spec next to that file must be a real test. npm test fails while the spec still contains implement this test.

Generator	Output
types	src/generated/types.ts, src/generated/identity.ts
queries	list and get
handlers	mutation handlers and src/generated/routes.ts
forms	one HTML form per mutation
pages	src/generated/page.html
logic	touch: true rule and spec

What generation buys you

You pay the model edit. Clay writes the files. The clips type the edit in vi, then show git diff.

The model edit is the whole change

Adding archive to clay/model.json is 15 lines of JSON. Clay writes 58 lines across 7 files: the form, the handler, the page, the route, the type, and the touch file with its spec. git diff --stat is that count. You pay an LLM for the 15 lines. Clay writes the 58. That is the token efficiency of this example.

Shelf is one entity, with no relations, in TypeScript. A larger model writes more from the same kind of edit, and a language with more boilerplate writes more still. This diff is the small case.

One change, the files that use it

Add a field. Clay rewrites the type and the page. Handlers and queries stay as they are. The touch file still builds a Note without the new field, so tsc fails until you update that file.

Add a mutation. Clay writes the form, the handler, and the touch pair. The new spec is a scaffold. npm test fails until that test is a real test.

The same move works in a template. One line in the form template adds a Cancel button to every mutation form.

The model names its own keys

clay/validate-model.ts checks clay/model.json before Clay runs. This check belongs to Shelf. An unknown key fails, and the error names the allowed keys. The mutation list is mutations. The check makes the model a fixed reference. Every generated file is checked against that source.

Place	Allowed keys
file	name, generators, model
model	identity, types
role	name, permissions
type	name, category, fields, queries, mutations
field	name, type, required, primary, description
query	name, permission, description
mutation	name, permission, description, input
input	fields

category is entity. A field type is uuid, string, or boolean. A query name is list or get. The entity has one primary field, and its name is id. Each permission appears on a role. get takes that id. list takes no input. A mutation other than create takes an id input. create does not take id.

Generated files stay closed

clay init-claude writes .claude/settings.json. Before an Edit or a Write, Claude Code runs clay check-generated. A generated path is refused. The touch file under src/logic/ is allowed, because Clay leaves it after the first write. That file is where the business rule lives, so the types and the tests matter there. The clip is a small agent transcript. The refusal is the hook. See AI Integration and check-generated.

The role check lives in the template

The role check is one line in the handler template. Clay copies it into every handler. A reader who calls a mutation gets HTTP 403 from that check. A handler carries the check because the template carries it.

Commands

Command	Action
npm run dev	Serve the page on port 4317
npm run validate	Reject a model that renames a concept or adds an unknown key
npm run generate	Validate the model, then run Clay
npm run typecheck	Run tsc
npm test	Require a real spec for each touch file, then run the tests
npm run check	Validate, typecheck, and test
npm run gifs	Record the clips above

Record the clips again with VHS on your PATH:

npm run gifs

The script returns the model to the baseline when it finishes. The baseline has no pinned field and no archive mutation.

Local Clay checkout

The dependency is the published clay-generator package. To use a sibling checkout at ../clay instead:

cd ../clay
npm link
cd ../clay-example
npm link clay-generator
